Combo Bodies
At the crossroads of ingenuity and efficiency lies the Combo Body from Knapheide. By combining the practicality and versatility of the ever-popular Service Body (front) and Platform Body (rear), the Combo Body is an ideal solution for the needs of virtually any line of work nationwide. Multiple configurations of the Combo Body allow you to get the most practical upfit to meet your needs. Available configurations include DRW in 10’ and 12’ lengths, 40” tall side packs with flip tops, 46” and 60” tall side packs (no flip tops). See why professionals from multiple industries are choosing the Combo Body to handle the demands of their jobsites.
Request a Quote
Complete our online quote request form and we'll help you get in touch with the right Knapheide distributor or dealer to meet your needs and get you a vehicle quote.
Automotive Latch
Automotive quality, paddle-activated rotary style latches make opening and closing easy. Low maintenance and stylish, the latches are covered under Knapheide's six year warranty.
E-Coat Immersion
Knapheide Bodies are fully immersed in Knapheide's 12-step, electrodeposition prime paint system for superior corrosion resistance.
Body Shell
Rugged 14-gauge, two-sided A-40 galvanneal steel body shell with a six year warranty. Complete undercoating provides an additional layer of corrosion protection.
Door Seals
Triple contact door seals provides protection against the outside elements for your tools and equipment.
Door Retainer
Double spring over-center door retainer on all doors eliminates involuntary swing and keeps the door in positive open or closed position.
Internal Latch Cover
Latch interior cover secures the latch to the door and protects the internal latch mechanisms from being damaged.
Security Ring
Adjustable security ring strikers provide strength, security, and a weather tight seal throughout the entire life of the body.
Compartment Doors
Features double-shell, 20-gauge, two-sided A-40 galvanneal steel compartment doors
Compartment Shelves
250 lb. capacity adjustable divider shelves made of rugged spangled galvanized steel. Divider slots on 4" centers. Shelves are covered by the Knapheide six year warranty.
Cargo Area
Oversized cargo area for transporting large tools, equipment, and inventory. Commercial grade Knapliner spray-on bedliner applied to cargo floor, sides, compartment tops, bulkhead, and tailgate for maximum corrosion resistance.
Receiver Hitch
Integrated Class V receiver hitch at rear of platform with safety chain attachment points and 7 way trailer plug, receiver hitch rated at 18,000 lbs.
LED Lights
Surface mount lighting system features LED S/T/T and B/U, LED strobe option with (8) selectable patterns and built-in reflectivity for additional safety
Stainless Steel Hinge
Continuous stainless steel hinge for unmatched security and corrosion resistance, backed by the Knapheide six year warranty.
Bottle Gas Retainer
Added protection and security for transport of bottled materials
LED Lights
Replacement for incandescent stop/tail/turn lights offering brighter light and a superior life span compared to incandescent lights
Overcab Material Rack
Increase storage space by getting ladders and other long tools or equipment up and out of the way, making room to haul more items in your cargo area.
Treadplate Trim
Trim for standard service bodies is added to the top of the slam tailgate and compartment tops. Can also be added to standard or flip top bodies.
| Model | Body Model | Total Length (Nominal) | Body Height | Body Width | Compartment Depth | Cargo Floor Width | Net Weight (lbs) | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 60" and 84" CA, Dual Rear Wheel | ||||||||||||||
| CB117D54 | 117" | 40" | 94" | 20" | 54" | 1402 | ||||||||
| CB117D54F40 | 117" | 40" | 94" | 20" | 54" | 1514 | ||||||||
| CB117D54H46 | 117" | 46" | 94" | 20" | 54" | 1488 | ||||||||
| CB117D54H60 | 117" | 60" | 94" | 20" | 54" | 1744 | ||||||||
| CB145D54 | 145" | 40" | 94" | 20" | 54" | 1712 | ||||||||
| CB145D54F40 | 145" | 40" | 94" | 20" | 54" | 1857 | ||||||||
| CB145D54H46 | 145" | 46" | 94" | 20" | 54" | 1821 | ||||||||
| CB145D54H60 | 145" | 60" | 94" | 20" | 54" | 2128 | ||||||||
Combo Body on Ford
Combo Body on Ford
Combo Body on Ford
Combo Body on Ford
See the New Combo Body from Knapheide
Combining a service body (front) and platform (rear) to provide maximum functionality and versatility, Knapheide’s new Combo Body is applicable for practically any vocation nationwide. See more in our walk-around…
READ MORE »
