Utility Van Bodies
KUV Steel Utility Van Bodies create optimized organization for the technician, dividing the storage space into manageable compartments that are externally accessible from either side of the body. The technician pulls up to the jobsite, exits the cab and immediately has quick access to the tools and parts they need without having to crawl into the cargo area. Dedicated conduit chutes enable the technician to store longer items without cluttering the floor of the oversized cargo area. Knapheide’s KUV is constructed of rugged galvanneal steel so the technician can have confidence it will provide years of reliable service. More contractors and technicians utilizing an enclosed utility body as their work vehicle choose a Knapheide KUV.
Say goodbye to crawling around in the back of your cargo van endlessly searching for tools, parts and equipment. Invest in a KUV and get more billable hours out of your day.
Request a Quote
Complete our online quote request form and we'll help you get in touch with the right Knapheide distributor or dealer to meet your needs and get you a vehicle quote.
Search Dealer Inventory
Search local commercial dealer inventory that's ready for work. This is the fastest way to get a Knapheide work vehicle.
Door Seals
Triple contact door seals provides protection against the outside elements for your tools and equipment.
Door Retainer
Double spring over-center door retainer on all doors eliminates involuntary swing and keeps the door in positive open or closed position.
Compartment Shelves
250 lb. capacity adjustable divider shelves made of rugged spangled galvanized steel. Divider slots on 4" centers. Shelves are covered by the Knapheide six year warranty.
Stainless Steel Hinge
Continuous stainless steel hinge for unmatched security and corrosion resistance, backed by the Knapheide six year warranty.
Automotive Latch
Automotive quality, paddle-activated rotary style latches make opening and closing easy. Low maintenance and stylish, the latches are covered under Knapheide's six year warranty.
Interior Light Guard
Interior light guards provide protection for recessed lighting and wiring package.
Internal Latch Cover
Latch interior cover secures the latch to the door and protects the internal latch mechanisms from being damaged. Appearance may vary.
Security Ring
Adjustable security ring strikers provide strength, security, and a weather tight seal throughout the entire life of the body.
Return Flange Floor
Exclusive "Return Flange" floor design provides support for side compartments, adds floor strength, and eliminates rust-prone exposed seam between floor and side compartments.
Body Shell
Rugged 14-gauge, two-sided A-40 galvanneal steel body shell with a six year warranty. Complete undercoating provides an additional layer of corrosion protection.
Nitrogen Gas Struts
Rear cargo doors employ nitrogen gas struts for smooth opening and closing operation.
E-Coat Immersion
Knapheide Bodies are fully immersed in Knapheide's 12-step, electrodeposition prime paint system for superior corrosion resistance.
Work Surface Horizontal Compartment
Horizontal compartment drops down to 90 degrees and can serve as a flat panel work surface on the jobsite.
Conduit Chutes
Two lockable conduit chutes with automotive style latches to transport copper pipes, PVC, conduit, and longer items.
Flat Panel Surface
Flat panel surface ideal for applying company logos, graphics, and contact information to create a rolling billboard.
Power Locks-Master Locking System
Power Locks with key fob to lock and unlock compartment and rear cargo doors (Power Locks are standard on KUV models for Ford Transit and Ram ProMaster cutaway chassis, Master Locking System standard on KUV models for Ford E-Series and GM Express/Savana cutaway chassis).
Rear Cargo Doors
Double panel rear cargo doors lock and seal into the body frame. Doors are constructed of 20 gauge galvanneal steel doors and employ slam latches.
Cargo Area With Cab Access Door
Spacious cargo area for transporting oversized inventory, tools, and equipment. Sliding cab access door with window can be locked from the cab and secured in either an open or closed position.
Interior Dome Lights
Two interior dome lights in cargo area for improved visibility in low light conditions, light switch located inside the rear cargo doors.
Grab Handle
Interior cargo area grab handle located directly inside the rear cargo doors on the curb side for easy and safe access.
LED Lights
Surface mount lighting system features LED S/T/T and B/U, LED strobe option with (8) selectable patterns and built-in reflectivity for additional safety
ABS Partition
Refined ABS partition is equipped with a sliding cab access door and window. The door's slam latch can be locked from the cab and secured in either an open or closed position.
Wind Deflector
Aerodynamic wind deflector mounted on body above cab. Available on all models except KUV129SU and KUV129SL.
Overhead Bow Ladder Rack
Constructed from aluminum and aluminum pipe. Choose from 2 bow or 3 bow mode. Available for KUV or KUVcc body.
Pull-Out Tray
Heavy duty pull-out tray rated at 500 lb. capacity.
Tie Downs
Ideal for safely securing heavy equipment in your cargo area. Zinc-plated. Rated at 2,000 lbs.
Codeable Padlock
Padlock learns your vehicle ignition key code and eliminates the need to carry both ignition key and padlock key.
E-Track
Secure large items in open or enclosed cargo area. Available as factory install with one row or two rows of E-track. Multiple add-on accessories available. Appearance may vary.
LED Compartment Lighting
Ideal for Service, Utility or Gooseneck body. Controlled and operated via vehicle up fitter switch. Switch kit and door activated switch kits also available. Multiple lengths available.
Liftgates
Manufactured by Tommy Gate. Available in steel or aluminum on certain KUV, KC and KSV bodies. Not compatible with SRW models. Maximum capacity is 1,300 lbs. Vertical travel up to 40 inches.
Power Locks
Available option for Service Bodies and KUV models using Ford E-Series or GM Express/Savana cutaway chassis. Standard feature on KUV models using Ford Transit or Ram ProMaster cutaway chassis. Integration with chassis keyless entry system (if equipped) allows for both body and cab to be operated with chassis key fob.
Rear Vision Camera
Includes a 7" full color LCD monitor with audio. Features infrared vision to provide adequate vision at night.
Ladder Rack
Available for KUV or Canopy Roof body. Spring over center clamps hold ladder with a padlock tab for added security.
Vise Bracket
Compatible with most Service, Utility and Line bodies. Steel construction. Mounting surface pre-punched to accommodate multiple sizes of Wilton vise.
Aluminum Mechanics Drawers
Aluminum alloy construction manufactured by C-Tech. Available in multiple configurations. Rated for maximum of 250 lbs. Appearance may vary.
Bumpers
Multiple material construction available including Grip-Strut and Galva-Grip. Available in multiple finishes.
Side Access Doors
Ideal for quick and effortless side access to the interior of your KUV or KUVcc cargo area. Available for all KUV and KUVcc bodies excluding the KUV129SU.
Receiver Hitch
Class V receiver hitch (with 12,000 lb. max rating) is available on Ford E-Series and GM Express/Savanna. Class IV receiver hitch (with a 6,000 lb. max rating) is available on Ford Transit and Ram ProMaster.
Spare Tire Retainer
Accepts tires as small as 14" up to 22.5", with up to 6" of vertical adjustment. Can be mounted on the street side of the cargo positioned close to the front.
Rear Door Windows
Provides increased visibility into cargo area
SpitzLift
Mounted, lightweight crane provides increased efficiency for lifting heavy objects on the job site
Drop Down Ladder Rack
Provides secure transportation and convenient access for ladder storage
Upper Side Glass
Provides increased natural light in cargo area
| Model | Chassis CA | Applicable Chassis | Body Length (Nominal) | Body Height | Body Width | Compartment Depth | Clear Door Width | Clear Door Height | Interior Clear Height | Net Weight (lbs) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Ford E-Series and GM G-Series Single Rear Wheel | ||||||||||||||||||||
| KUV129SU | 80" | 1992 and later Ford E-350 (138" WB) 1997 & later GM G-Van (139" WB) | 129.25" | 70" | 83" | 14.5" | 49.5" | 49.3" | 55.8" | 1731 | ||||||||||
| KUV129SL | 80" | 1993 and later Ford E-350 (138" WB) 1997 & later GM G-Van (139" WB) | 129.25" | 78" | 83" | 14.5" | 49.5" | 54.3" | 63.8" | 1873 | ||||||||||
| KUV129SH | 80" | 1994 and later Ford E-350 (138" WB) 1997 & later GM G-Van (139" WB) | 129.25" | 90" | 83" | 14.5" | 49.5" | 66.3" | 75.8" | 2053 | ||||||||||
| Ford E-Series and GM G-Series Dual Rear Wheel | ||||||||||||||||||||
| KUV129DL | 80" | 1992 and later Ford E-350 (138" WB) 1997 and later GM G-Van (139" WB) | 129.25" | 78" | 94" | 14.5" | 60.5" | 54.3" | 63.8" | 2047 | ||||||||||
| KUV129D20L | 80" | 1993 and later Ford E-350 (138" WB) 1997 and later GM G-Van (139" WB) | 129.25" | 78" | 94" | 20" | 49.5" | 54.3" | 63.8" | 1973 | ||||||||||
| KUV129DH | 80" | 1994 and later Ford E-350 (138" WB) 1997 and later GM G-Van (139" WB) | 129.25" | 90" | 94" | 14.5" | 60.5" | 66.3" | 75.8" | 2198 | ||||||||||
| KUV129D20H | 80" | 1995 and later Ford E-350 (138" WB) 1997 and later GM G-Van (139" WB) | 129.25" | 90" | 94" | 20" | 49.5" | 66.3" | 75.8" | 2222 | ||||||||||
| KUV153DL | 100" | 1992 and later Ford E-350/450 (158" WB) 1997 and later GM G-Van (159" WB) 2003-2009 GM C4500/5500 100 CA Commercial Cutaway (165.5" WB) | 153.25" | 78" | 94" | 14.5" | 60.5" | 54.3" | 63.8" | 2347 | ||||||||||
| KUV153D20L | 100" | 1993 and later Ford E-350/450 (158" WB) 1997 and later GM G-Van (159" WB) 2003-2009 GM C4500/5500 100 CA Commercial Cutaway (165.5" WB) | 153.25" | 78" | 94" | 20" | 60.5" | 54.3" | 63.8" | 2382 | ||||||||||
| KUV153DH | 100" | 1994 and later Ford E-350/450 (158" WB) 1997 and later GM G-Van (159" WB) 2003-2009 GM C4500/5500 100 CA Commercial Cutaway (165.5" WB) | 153.25" | 90" | 94" | 14.5" | 60.5" | 66.3" | 75.8" | 2517 | ||||||||||
| KUV153D20H | 100" | 1995 and later Ford E-350/450 (158" WB) 1997 and later GM G-Van (159" WB) 2003-2009 GM C4500/5500 100 CA Commercial Cutaway (165.5" WB) | 153.25" | 90" | 94" | 20" | 49.5" | 66.3" | 75.8" | 2553 | ||||||||||
| Ram ProMaster Cutaway Chassis | ||||||||||||||||||||
| KUV129SU-RP | 81" | 2014 AND LATER RAM PROMASTER CUT-AWAY W/136" WB | 129.25" | 74" | 83" | 14.5" | 49.5" | 50.3" | 59.8" | 1903 | ||||||||||
| KUV129SL-RP | 81" | 2014 AND LATER RAM PROMASTER CUT-AWAY W/136" WB | 129.25" | 78" | 83" | 14.5" | 49.5" | 54.3" | 63.8" | 1892 | ||||||||||
| KUV129SH-RP | 81" | 2015 AND LATER RAM PROMASTER CUT-AWAY W/136" WB | 129.25" | 90" | 83" | 14.5" | 49.5" | 66.3" | 75.8" | 2269 | ||||||||||
| Ford Transit Single Rear Wheel Cutaway Chassis | ||||||||||||||||||||
| KUV129SU-FT | 82.5" | 2014 AND LATER FORD TRANSIT SRW CUT-AWAY W/138" WB | 129.25" | 73.1" | 83.1" | 14.5" | 49.9" | 50.5" | 59.5" | 1898 | ||||||||||
| KUV129SL-FT | 82.5" | 2015 AND LATER FORD TRANSIT SRW CUT-AWAY W/138" WB | 129.25" | 78.3" | 83.1" | 14.5" | 49.9" | 55.5" | 64.5" | 1884 | ||||||||||
| KUV129SH-FT | 82.5" | 2016 AND LATER FORD TRANSIT SRW CUT-AWAY W/138" WB | 129.25" | 90.0" | 83.1" | 14.5" | 49.9" | 66.0" | 76.5" | 2258 | ||||||||||
| Ford Transit Dual Rear Wheel Cutaway Chassis | ||||||||||||||||||||
| KUV129DU-FT | 82.5" | 2014 AND LATER FORD TRANSIT DRW CUT-AWAY W/138" WB | 129.25" | 73.1" | 83.1" | 14.5" | 49.9" | 50.5" | 59.5" | 1912 | ||||||||||
| KUV129DL-FT | 82.5" | 2015 AND LATER FORD TRANSIT DRW CUT-AWAY W/138" WB | 129.25" | 78.3" | 83.1" | 14.5" | 49.9" | 55.5" | 64.5" | 1902 | ||||||||||
| KUV129DH-FT | 82.5" | 2016 AND LATER FORD TRANSIT DRW CUT-AWAY W/138" WB | 129.25" | 90.0" | 83.1" | 14.5" | 49.9" | 66.0" | 76.5" | 2003 | ||||||||||
| KUV153DU-FT | 100" | 2014 AND LATER FORD TRANSIT DRW CUT-AWAY W/156" WB | 153.25" | 73.1" | 83.1" | 14.5" | 49.9" | 50.5" | 59.5" | 2209 | ||||||||||
| KUV153DL-FT | 100" | 2015 AND LATER FORD TRANSIT DRW CUT-AWAY W/156" WB | 153.25" | 78.3" | 83.1" | 14.5" | 49.9" | 55.5" | 64.5" | 2190 | ||||||||||
| KUV153DH-FT | 100" | 2016 AND LATER FORD TRANSIT DRW CUT-AWAY W/156" WB | 153.25" | 90.0" | 83.1" | 14.5" | 49.9" | 66.0" | 76.5" | 2574 | ||||||||||
| Sprinter Cutaway Chassis | ||||||||||||||||||||
| KUV136DL-SP | 85.2" | 2017 AND LATER SPRINTER CUT-AWAY W/144" WB | 137.25" | 82" | 83" | 14.5" | 49.5" | 55.7" | 62.5" | 2031 | ||||||||||
| KUV136DH-SP | 85.2" | 2018 AND LATER SPRINTER CUT-AWAY W/144" WB | 137.25" | 94" | 83" | 14.5" | 49.5" | 66.3" | 74.5" | 2239 | ||||||||||
KUV Body on Ford
KUV Body on Ford
KUV Body on Ford
KUV Body on Ram
KUV Body on Ram
KUV Body on GM (Chevrolet)
KUV Body on GM (Chevrolet)
